NM400/500 NM550 wear resistant steel plate High strength alloy steel plate
Standard of ASTM,ASME,BS1501,EN10207,EN10025,EN10028,DIN,wear resistant steel plates which grades are NM300,NM360,NM400,NM450,NM500,NM550,NM600,SB40,SB45,SB50,400F,400V,500F,500V.If you want to know steel plates' mechanical property,chemical composition,specification and other techanical conditions,please feel freel to contact me or send email to sophialee0215(at)gmail(dot)com
| Material | Thickness(mm) | Strength of extension | Elongation | Impact energy(vertical) | BH(Brinell Hardness) |
| ℃ | Akv/J |
| NM300 | 6-80 | ≥1000 | ≥14 | -20 | ≥24 | 270-300 |
| NM360 | 6-80 | ≥1100 | ≥12 | -20 | ≥24 | 330-390 |
| NM400 | 6-80 | ≥1200 | ≥10 | -20 | ≥24 | 370-430 |
| NM450 | 6-80 | ≥1250 | ≥7 | -20 | ≥24 | 420-480 |
| NM500 | 6-70 | / | / | / | / | ≥470 |
| NM550 | 6-70 | / | / | / | / | ≥530 |
| HarDox450 | 5-50 | ≥1400 | 10 | -40 | ≥35 | 425~475 |
| HarDox500 | 5-50 | / | / | -40 | ≥30 | 450~540 |
| HarDox550 | 5-50 | / | / | -40 | ≥24 | 450~540 |
Wear resistant steel plate |
| Length | 4m-12m or as required |
| Width | 0.6m-3m or as required |
| Thickness | 3-300mm |
| Standard | AISI,ASTM,DIN,JIS,GB,JIS,SUS,EN,etc. |
| Technique | Hot rolled |
| Surface Treatment | Clean, blasting and painting according to customer requirement |
| Thickness tolerance | ±0.1mm |
| Material | NM360,NM400,NM450,NM500,NR360,NR400
AR400,AR450,AR500,AR550
HARDOX400,HARDOX450,HARDOX500,HARDOX600
XAR400,XAR450,XAR500,XAR600
QUARD400,QUARD450,QUARD500
FORA400,FORA500
RAEX400,RAEX450,RAEX500
JFE-EH360, JFE-EH400,JFE-EH500 |
| Application | It is widely used in mining machinery,environmental protection machinery,
cement machinery, engineering machinery etc due to it is high wear resistance. |
| Shipment time | Within 15-20 workdays after receiving deposit or L/C |
| Export packing | Waterproof paper, and steel strip packed.
Standard Export Seaworthy Package.Suit for all kinds of transport,or as required. |
1. Main application
For plastic moulds, cold work die and mould base as well as constructional part
2. Manufacturers
An Steel, Wuyang Steel, Xiang Steel, Jiu Steel, Bao Steel, etc.
3. Delivery condition
Hot rolling
Hardness: annealed HB≤210
Diameter: 12~500mm Length:1800~12000mm
4. General
High quality carbon constructional steel
Packing
FAQ
Q. How long will it take to execute my order?
A:Our normal lead time is 7-15 working days.,but we have many models in stock,We will let you know the estimated lead time after payment ASAP.
Q Can I have a sample for testing?
A: Free simples, you just need pay the freight.
Q. Do you have products in stock?
A: Because we only do wholesale, usually do not have stock, we provide fast shipping for most products, If there is any stock, we will inform you with details.
Q Do you have inspection procedures for the products?
A:100% self-inspection before packing
Q Can I have a visit to your factory before the order?
A: Sure,welcome to visit our factory.
